PROCESSOR

Supports  9th/8th Gen Intel® Core™ / Pentium® Gold / Celeron® processors for LGA 1151 socket

Intel® B365 Chipset

MEMORY

•           4x DDR4 memory slots, support up to 64GB

•           Supports DDR4 2666/ 2400/ 2133 MHz

•           Supports Dual-Channel mode

•           Supports non-ECC, un-buffered memory

•           Supports Intel® Extreme Memory Profile (XMP)

SLOTS

•           1 x PCIe 3.0 x16 slot

•           2 x PCIe 3.0 x1 slots

ONBOARD GRAPHICS

•           1 x VGA port, supports a maximum resolution of 2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz

•           1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz

•           1 x HDMI™ port 1.4, supports a maximum resolution of 4096x2160@30Hz

STORAGE

Intel® B365 Chipset

•           6 x SATA 6Gb/s ports1

•           1 x M.2 slot (Key M)

o          Supports up to PCIe 3.0 x4 and SATA 6Gb/s

o          Supports 2242/ 2260 /2280/ 22110 storage devices

o          Intel® Optane™ Memory Ready2

1.         The SATA1 connector will be unavailable when an M.2 SATA SSD module has been installed in the M.2_1 slot.

2.         Before using Intel® Optane™ memory modules, please ensure that you have updated the drivers and BIOS to the latest version from MSI website.

USB

Intel® B365 Chipset

•           8 x USB 3.1 Gen1 (SuperSpeed USB) ports (3 Type-A & 1 Type-C ports on the back panel, 4 ports available through the internal USB connectors)

•           6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB connectors)

AUDIO

Realtek® ALC892 Codec

•           7.1-Channel High Definition Audio

LAN

•           1 x Realtek RTL8111H Gigabit LAN controller

INTERNAL CONNECTORS

•           1 x 24-pin ATX main power connector

•           1 x 8-pin ATX 12V power connector

•           6 x SATA 6Gb/s connectors

•           2 x USB 3.1 Gen1 connector (supports additional 4 USB 3.1 Gen1 ports)

•           2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)

•           1 x 4-pin CPU fan connector

•           2 x 4-pin system fan connectors

•           1 x Front panel audio connector

•           1 x Parallel port connector

•           1 x Serial port connector

•           2 x Front panel connectors

•           1 x TPM module connector

•           1 x 4-pin RGB LED connector

•           1 x Chassis Intrusion connector

•           1 x Clear CMOS jumper

BACK PANEL PORTS

1.         Mouse Port

2.         VGA Port

3.         HDMI Port

4.         LAN Port

5.         USB 3.1 Gen1

6.         USB 3.1 Gen1 Type A

7.         Keyboard Port

8.         DVI-D Port

9.         USB 2.0 Ports

10.       USB 3.1 Gen1 Type C

11.       HD Audio Connectors

DIMENSIONS

•           9.6 in. x 9.6 in. (24.4 cm x 24.4 cm)

•           Micro-ATX Form Factor

MOUNTING

8 mounting holes

OPERATING SYSTEM

Support for Windows® 10 64-bit
