MANUFACTURER: HP / INTEL
PART NUMBER: 1XM51AA
CPU SERIES: 1ST GEN INTEL XEON SCALABLE ( SILVER 4100 SERIES )
PROCESSOR CODE NAME: SKYLAKE
SOCKETS SUPPORTED: FCLGA3647 ( SOCKET P )
COMPATIBILITY: HP Z6 G4 WORKSTATION
KIT INCLUDES: ( 1 ) ONE PROCESSOR ( 1 ) ONE HEATSINK / FAN ASSY ( 1 ) ONE RISER BOARD ( 1 ) ONE RISER BOARD TRAY / COOLING SOLUTION ( 1 ) ONE RISER BOARD SUPPORT BRACKET ( 1 ) ONE POWER CABLE

PERFORMANCE

CPU FREQUENCY: 1.80GHZ
CPU MAX TURBO FREQUENCY: 3.00GHZ
MULTI-CORE: 8-CORE
THREADS: 16
CACHE: 11MB L3
NUMBER OF UPI LINKS: 2
LITHOGRAPHY: 14 NM
THERMAL DESIGN POWER: 85W

SUPPLEMENTAL INFORMATION

EMBEDDED OPTIONS AVAILABLE: NO

MEMORY SPECS

MAX MEMORY SIZE ( DEPENDENT ON MEMORY TYPE ): 768GB
MEMORY TYPES: DDR4-2400
MAX MEMORY SPEEDS: 2400 MHZ
MAX NUM. MEMORY CHANNELS: 6
ECC MEMORY SUPPORTED: YES

EXPANSION OPTIONS

SCALABILITY: 2S
PCI EXPRESSION REVISION: 3.0
MAX NUM. OF PCI LANES: 48

ADVANCED TECHNOLOGIES

INTEL OPTANE MEMORY SUPPORTED: NO
INTEL SPEED SHIFT TECHNOLOGY: YES
INTEL TURBO BOOST MAX TECHNOLOGY 3.0: NO
INTEL TURBO BOOST TECHNOLOGY: 2.0
INTEL VPRO TECHNOLOGY: YES
INTEL HYPER THREADING TECHNOLOGY: YES
INTEL VIRTUALIZATION TECHNOLOGY ( VT-X ): YES
INTEL VIRTUALIZATION TECHNOLOGY FOR DIRECT I/O ( VT-D ): YES
INTEL VT-X WITH EXTENDED PAGE TABLES ( EPT ): YES
INTEL TSX-NI: YES
INTEL 64 BIT: YES
INSTRUCTION SET EXTENSIONS: INTEL SSE4.2, INTEL AVX, INTEL AVX2, INTEL AVX-512
NUMBER OF AVX-512 FMA UNITS: 1
ENHANCED INTEL SPEEDSTEP TECHNOLOGY: YES
INTEL VOLUME MANAGEMENT DEVICE ( VMD ): YES

SECURITY & RELIABILITY

INTEL ADVANCED ENCRYPTION STANDARD AES NEW INSTRUCTIONS: YES
INTEL TRUSTED EXECUTION TECHNOLOGY: YES
EXECUTE DISABLE BIT: YES
MODE BASED EXECUTE CONTROL ( MBE ): YES
