TP-Link WBS210 | 2.4GHz 300Mbps Outdoor Wireless Base Station | 718F

2,450,000

ĐẶT HÀNG

Giao hàng tận nơi

Thanh toán khi nhận hàng

Đổi trả trong 5 ngày
Không được đổi trả với lý do "không vừa ý"

36 tháng bằng hóa đơn mua hàng

Bảo hành chính hãng toàn quốc
Hotline: 19002074 Ấn Phím 6

HARDWARE FEATURES
Processor	Qualcomm Atheros Enterprise AR9350B 560MHz CPU, MIPS 74Kc
Memory	64MB DDR2 RAM, 8MB Flash
Interface	1 10/100Mbps Shielded Ethernet Port (LAN0/POE) 1 10/100Mbps Shielded Ethernet Port (LAN1) 2 RP-SMA Female 1 Grounding Terminal 1 Reset Button
Power Supply	Passive Power over Ethernet via LAN0 (+4,5pins; -7,8pins) Voltage range: 16-27VDC
Dimensions ( W x D x H )	198 x 74 x 40 mm
Protection	15KV ESD Protection 6KV Lightning Protection
Enclosure	Outdoor ASA stabilized plastic material IP65 water and dust proof Certification

WIRELESS FEATURES
Wireless Standards	IEEE 802.11b/g/n
Proprietary Protocol	TDMA Mode (with Pharos MAXtream enabled)
Wireless Speeds	Up to 300Mbps (40MHz,Dynamic) Up to 144.4Mbps (20MHz,Dynamic) Up to 72.2Mbps (10MHz,Dynamic) Up to 36.1Mbps (5MHz,Dynamic)
Frequency	2.4~2.483GHz Note: Available operating frequency may vary depending on the limitation of the contries or regions in which the device is used.
Transmission Power	27dBm/500mW (Adjustable power by 1dBm) Note: Maximum transmission power may vary across different channels depending on the limitations of the countries or regions in which the device is used.

SOFTWARE FEATURES
Operating Modes	AP / Client / Bridge /Repeater AP Router Mode / AP Client Router(WISP Client) Mode
Network Configuration	WAN: Static/Dynamic/PPPoE/L2TP/PPTP LAN: Static/Dynamic/Dynamic/DHCP Forwarding: DMZ/ALG/UPnP/Virtual Server/Port Trigger Security: SPI Firewall/Ping Forbidden/VPN/DOS Protection Access Control Static Routing Bandwidth Control IP & MAC Binding
Wireless Configurations	Pharos MAXtream TDMA Technology 802.11b/g/n Modes Selectable Channel Width: 5/10/20/40MHz Automatic Channel Selection Transmission Power Control Dynamic Frequency Selection (DFS) WDS Enable/Disable Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption, 64/128/152-bit WEP Encryption SSID Broadcast Enable/Disable Multi-SSID with VLAN Tagging (AP mode only) Distance/ACK Timeout Setting Wireless MAC Address Filter Wireless Advanced: > Beacon Interval/RTS Threshold/Fragmentation Threshold/DTIM Interval/AP Isolation/ Short GI/Wi-Fi Multimedia
Management	Discovery and Remote Management via Pharos Control application HTTP/HTTPS Web-based management System Log SNMP Agent(v2c) Ping Watch Dog Dynamic DDNS SSH Server
System Tools	Wireless Signal Quality Indicators: Signal Strength/Noise/Transmit CCQ/CPU/Memory Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP Spectrum Analyzer Speed Test Ping Traceroute
System-level Optimizations	802.11b/g/n Tx beamforming technology Optimized IGMP Snooping/Proxy for multicast applications Hardware watch dog

OTHERS
Certification	CE, FCC, RoHS, IP65
Package Contents	Outdoor Wireless Base Station 24V 0.6A Passive PoE Adapter Pole Mounting Kit AC Power Cord Quick Installation Guide
System Requirements	Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux. Note: We recommend you to use one of following Web browsers for an improved user experience: Google Chrome, Safari, and Firefox. IE browsers are not recommended.
Environment	Operating Temperature: -30°C~70°C (-22℉~158℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~95% non-condensing
Warranty	Limited 3-Year Warranty For further information on our warranty policy please visit: http://www.tp-link.com.au/support/rma

Bảo hành	36 tháng
VAT	Đã bao gồm VAT
