| PERFORMANCE |
| Processor
|
Intel® Core™ i3-13100, 4C (4P + 0E) / 8T, P-core 3.4 / 4.5GHz, 12MB
|
| Graphics |
Integrated Intel® UHD Graphics 730
|
| Chipset |
Intel® B760 Chipset
|
| Memory |
1x 4GB UDIMM DDR4-3200
|
| Memory Slots |
Two DDR4 UDIMM slots, dual-channel capable
|
| Max Memory
|
Up to 64GB DDR4-3200
|
| Storage |
256GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0
|
| Storage Support
|
Up to two drives, 1x 3.5" HDD + 1x M.2 SSD • 3.5" HDD up to 2TB • M.2 SSD up to 1TB
|
| Card Reader |
None
|
| Optical |
None
|
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC222-CG codec
|
| Speakers |
2Wx1
|
| Power Supply |
180W 85%
|
| Keyboard |
USB Calliope Keyboard, Black, English
|
| Mouse |
USB Calliope Mouse, Black
|
| Optional Bay |
None
|
| Expansion Slots |
- One PCIe® 4.0 x16, full-height, half-length
- Two PCIe® 3.0 x1, full-height, half-length
- Two M.2 slots (one for WLAN, one for SSD)
|
| Case Color |
Black
|
| System Fan |
1x Front
|
| Form Factor |
Tower (13.6L)
|
| Dimensions (WxDxH)
|
145 x 294 x 340 mm (5.71 x 11.57 x 13.39 inches)
|
| Weight
|
Around 5.5 kg (12.1 lbs)
|
| CONNECTIVITY |
| Ethernet |
Intel® I219-V, 1x RJ45
|
| WLAN + Bluetooth
|
Intel® Wi-Fi® 6 AX201, 11ax 2x2 + BT5.1
|
| Front Ports |
- 1x USB-C® 3.2 Gen 1 (support data transfer and 5V@3A charging)
- 2x USB 3.2 Gen 1
- 2x USB 3.2 Gen 2
- 1x headphone / microphone combo jack (3.5mm)
- 1x microphone (3.5mm)
|
| Rear Ports |
- 4x USB 2.0 (one supports Smart Power On)
- 1x HDMI® 1.4b
- 1x DisplayPort™ 1.4
- 1x VGA
- 1x Ethernet (RJ-45)
- 1x headphone (3.5mm)
- 1x serial (9-pin)
|
| Optional Rear Ports (configured) |
None
|
| Monitor Cable |
None
|
| SECURITY & PRIVACY |
| Security Chip |
Discrete TPM 2.0, TCG certified
|
| Fingerprint Reader |
No fingerprint reader
|
| Physical Locks |
- Kensington® Security Slot™, 3 x 7 mm
- Padlock Loop
|
| Smart Cable Clip |
None
|
| Chassis Intrusion Switch |
None
|
| MANAGEABILITY |
| System Management |
Non-vPro®
|
| SERVICE |
| Base Warranty |
1-year, Courier or Carry-in
|
| Included Upgrade |
1Y Premier Support Upgrade from 1Y Courier/Carry-in
|
